SC / UPC SC / APC PLC Fiber Optic Splitter 1x2 Cassette Type

    Buy cheap SC / UPC SC / APC PLC Fiber Optic Splitter 1x2 Cassette Type from wholesalers

    Buy cheap SC / UPC SC / APC PLC Fiber Optic Splitter 1x2 Cassette Type from wholesalers
    • Buy cheap SC / UPC SC / APC PLC Fiber Optic Splitter 1x2 Cassette Type from wholesalers
    • Buy cheap SC / UPC SC / APC PLC Fiber Optic Splitter 1x2 Cassette Type from wholesalers

    SC / UPC SC / APC PLC Fiber Optic Splitter 1x2 Cassette Type

    Ask Lasest Price
    Brand Name : ANSHI
    Model Number : AS-OSC-1X2
    Certification : ISO9001, SGS
    Price : Negotiable
    Delivery Time : 10000pcs/week
    • Product Details
    • Company Profile

    SC / UPC SC / APC PLC Fiber Optic Splitter 1x2 Cassette Type


    ANSHI 1*2 SC/UPC SC/APC FC PLC Splitter FTTH LGX Box Type

    Key Specifications/Special Features:

    PLC splitters are single mode splitters with an equal split ratio from one input fiber to multiple output fibers
    This PLC splitter is 1x2, with 1 input fiber and 2 output fibers, and is packed in insertion box, it can be fixed in different fiber distribution boxes and FTTH boxes


    Product Information:


    Place of origin: Zhejiang, China
    Fiber type: G657A1 or G652D
    Fiber length: >0.5m
    Box size: 130x100x25mm PC
    Delivery: free samples, and fast delivery, according to the quantity, we make the delivery within 3-10 working days, and if you are urgent for the products, just let me know, and we will try to ahead the delivery date

    Specifications:


    DescriptionUnit1x21x41x81x161x321x64
    Operating Wavelengthnm1310 ~ 1550nm
    Insertion LossdB3.67.210.213.516.220.5
    Polarization dependent lossdB0.20.20.30.30.30.4
    UniformitydB0.40.60.81.01.21.8
    DirectivitydB55
    Wave correlation lossdB0.5
    Working temperature-40℃~85℃

    The PLC Splitters is branching devices that is used to distribute optical signals to multiple locations for processing. In optical networks, it is often necessary to split an optical signal into many identical signals, or to combine many signals into a single signal. PLC Splitter (Planar lightwave circuit splitter) is a type of optical power management device that is fabricated using silica optical waveguide technology. They are designed for FTTx Passive Optical Networks, CWDM, DWDM and optical cable TV System. PLC Splitter is responsible to distribute optical signals from Central Office (CO) to multiple premise locations.We provides whole series of 1*N and 2*N splitter products that are tailored for specific applications. All prodcts meet GR-1209-CORE-2001 and GR-1221-CORE-1999 requirements.
