90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating

    Buy cheap 90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating from wholesalers

    Buy cheap 90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating from wholesalers
    • Buy cheap 90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating from wholesalers
    • Buy cheap 90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating from wholesalers
    • Buy cheap 90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating from wholesalers

    90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating

    Ask Lasest Price
    Brand Name : ANSHI
    Model Number : XL-4011B-6A
    Certification : SGS, ISO9001, DAS
    Price : Negotiable
    Supply Ability : 30000 Pieces per day
    • Product Details
    • Company Profile

    90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating

    Network RJ45 Keystone Jack 90 Degree CAT6A Keystone Jack


    Electrical
    Voltage Rating :AC 125V
    Current Rating :1.5 AMPS
    Insulation Resistance:500MΩ Min
    Withstand Voltage:DC 1000V RMS 50-60Hz Min
    Contact Resistange:20MΩ Max
    Mechanical
    Insertion Force:2 pins 3.5N 4 pins 5N 6 pins 7.5N 8 pins 9 N
    Retention Strength:70N between jack and plaug;60N between wire and IDC
    Durability:Jack 700 mating cycles mini; IDC contact 100 stripper cycles mini
    Wire:AWG 24-26
    Material
    Housing:PC(UL94V-0);ABS(UL94V-0);PC/ABS(UL94V-0)
    IDC Hosing:PC(UL94V-0);PBT(UL94V-0)
    Spring Wire:T=0.35mm phosphor bronze alloy selective gold
    0.45 dia phosphor bronze gold plating over nickel
    IDC Contact :Phosphor bronze;Nickel plating
    Shielding:T=0.25mm copper alloy with tin plated gold
    Plating :3u inch,6u inch,10u inch,15u inch,20u inch,30u inch,50u inch
    Working Environment
    Temperature:-10°c-60°c
    Humidity:10-90%

    90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating90 Degree Network RJ45 Keystone Jack Cat6A UTP 8P8C With Gold Plating
