AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU
Product Overview
AS-ONU49 model ONU is a user terminal device independently
developed in line with such industrial background.The device has
built-in two-layer switching function and three-layer routing
function. With compact structure and small appearance, it is a kind
of FTTH optical network unit with high performance and low power
consumption, which is very suitable for the application
requirements of various data services in FTTH networking scenarios
of various operators.AS-ONU49 is an XPON product that can be
adapted to EPON and GPON networks without replacing equipment and
firmware.
Features
♦ Support EPON/GPON mode and switch mode automatically
♦ GPON:Compliance with IEEE 802.3ah & itu-t g.984.x standard
♦ GPON:8 T-CONTs,32 GEM Ports
♦ Integrate OMCI(GPON)/OAM(EPON) and TR-069 remote configuration
and maintenance
♦ Layer 3 Home Gateway/CPE features with Hardware NAT, support
Multiple WAN, Route/Bridge mode, etc
♦ Layer 2 Switching, support 802.1Q VLAN, 802.1P QOS, Bandwidth
Control, Spanning Tree, etc
♦ Bi-directional FEC
♦ Support firewall level Settings, support based on URL/MAC/ IP/
address frame filtering
♦ Support multicast IGMP v2 proxy/ snooping, support MLD proxy/
snooping
♦ Qos supports PQ, WRR, and CAR queue scheduling
♦ Provide Maximum rate 1775Mbps Wireless interface, 2T2R external
antenna, support multiple SSID Settings
♦ Support DDSN, ALG, DMZ and UPNP
♦ Provide POTS interface, support SIP protocol,POTS integrated
circuit test complies GR-909
Highlights
♦ Dual band Wi-Fi, Superior performance of Wireless 11n and 11ac
Transmission
♦ Compatible with 95% Third-party OLTs (Including
Huawei/ZTE/Fiberhome/BT-PON and so on)
♦ Spport EPON/GPON mode and switch mode automatically
♦ Support Route PPPoE/DHCP/Static IP and Bridge mode
♦ Support ONU auto-discovery/Link detection/remote upgrade of
software
♦ Support IPv4/IPv6 dual mode
♦ Support Firewall function and IGMP multicast feature
♦ Support LAN IP and DHCP Server configuration
♦ Support Port Forwarding and Loop-Detect
