    110 Idc Rack Mount Patch Panel 19 Inch Cat6 Unshield UTP With Cable Manager

    Ask Lasest Price
    Brand Name : ANSHI
    Model Number : XL-4017
    Certification : SGS, DAS, ISO9001
    Price : Negotiable
    Supply Ability : 5000 Pieces Per Week
    • Product Details
    • Company Profile

    110 Idc Rack Mount Patch Panel 19 Inch Cat6 Unshield UTP With Cable Manager

    19 inch 1U RJ45 CAT6 Unshield UTP 110 IDC Rack Mount PATCH PANEL WITH CABLE MANAGER


    Standard requirements:

    • Meets ANSI/TIA/EIA-568-B.2 Category 6 requirements.
    • Meets TIA/EIATSB-40
    • Meets ISO/IEC Generic Cabling Standard 11801:2002 ed.2.0
    • Meets CENELEC Generic Cabling Standard EN50173-1:2002.

    Material :

    • Housing:0.06''(1.6mm) thicknss steel.
    • Cover:0.039''(1mm) thickness steel.
    • PCB(Printed circuit board): FR-4 0.06''(1.6mm) thickness,2/ayers.
    • Contacts: 0.018''(0.45mm) Phosphor bronze wth 50 micro inches(1.27 micron)
    • Gold plating on contact area
    • IDC: PC UL94V-O

    Electrical Characteristics:

    • According to UL1863
    • Current rating :1.5A Max
    • Voltage Rating: 150V
    • Contact resistance: 20m-ohm
    • Insulation resistance:500M-ohm
    • Dielectric withstand voltage:1000V AC RMS,60Hz/min.
